4 Programmable Relay ZEN
Specifications
■ General Specifications
■ Performance Specifications
Item Specification
ZEN-@0C@AR-A-V1 ZEN-@0C@D@-D-V1
Power supply
voltage
100 to 240 VAC 24 VDC
Rated power
supply voltage
85 to 264 VAC 20.4 to 26.4 VDC
Power
consumption
30 VA max. (With 3
Expansion Units
connected)
6.5 W max. (With 3
Expansion Units
connected)
Inrush current 40 A max. 10 A max.
Insulation
resistance
Between power supply AC external and input terminals, and relay output terminals:
20 M_ min. (at 500 VDC)
Dielectric strength Between power supply AC external and
input terminals, and relay output terminals: 2,300 VAC, 50/60 Hz for 1 minute with leakage current of
1 mA max.
Noise immunity Conforms to IEC61000-4-4, 2 kV
(power supply line)
Vibration
resistance
Conforms to JIS C0040, 10 to 57 Hz, amplitude 0.075 mm, 57 to 1,500 Hz, acceleration:
9.8 m/s2 80 minutes in X, Y, and Z directions (sweep time: 8 min (No. sweeps: 10 = 80 min.))
Shock resistance Conforms to JIS C0041. 147 m/s2, 3 times in X, Y, and Z directions.
Ambient
temperature
LCD-type CPU Unit (operation panel and
calendar/clock function): 0 to 55°C LED-type CPU Unit (no operation panel or calendar/clock function):
–25 to 55°C
Ambient humidity 10% to 90% (with no condensation)
Ambient
conditions
No corrosive gases
Ambient storage temperature LCD-type CPU Unit (operation panel and
calendar/clock function): –20 to 75°C LED-type CPU Unit (no operation panel or calendar/clock func-
tion): –40 to 75°C
Item Specification
Control method Stored program control
I/O control method Cyclic scan
Programming language Ladder diagram
Program capacity 96 lines (3 input conditions and 1 output per line)
Max. No. of control I/O points 44 points CPU Unit: 12 inputs and 8 outputs Expansion I/O Units: 4 inputs and 4 outputs each,
up to 3 Units.
LCD display 12 characters x 4 lines, with backlight (LCD-type CPU Unit only)
Operation keys 8 (4 cursor keys and 4 operation keys) (LCD-type CPU Unit only)
Memory backup Internal EEPROM (or optional Memory Cassette)
• User programs
• Parameter settings
Internal RAM, super-capacitor hold (or optional Battery Unit)
• Holding bits
• Holding timer and counter values
Super capacitor hold (or optional Battery Unit)
• Calendar and clock
Super-capacitor holding time 2 days min. (25°C)
Battery life (ZEN-BAT01) 10 years min. (25°C)
Time function (RTC) ZEN@0C1@@-@ only, accuracy: 1 to 2 min/month (at 25°C)
Terminal block Solid-line terminal block (Use solid lines or fine wiring terminals.)
Power supply holding time ZEN-@0C@AR-A: 10 ms min.ZEN-@0C@D@-D: 2 ms min.
Weight 300 g max.
