25
Using DABContinued
You can select a component for listening from the list of
scanned components produced by using the Auto Tuning
function.
1
Press the [MENU] button.
2
Turn the [ ] control to select Search
Mode and push the [ ] control.
3
Turn the [ ] control to select Com-
ponent and push the [ ] control.
4
Turn the [ ] control to select the com-
ponent you require.
You can select any component outside the ensemble.
You can sort and list scanned components by component
name, program type or alphabetical order.
You can then select the component you want to listen to
from the list.
Component Name
Sorts the components for each ensemble by component
name.
PTY
Sorts components by program type.
Alphabet
Sorts component names in alphabetical order.
1
Press the [MENU] button.
2
Turn the [ ] control to select Sort
Mode and push the [ ] control.
3
Turn the [ ] control to select the sort
mode required and push the [ ] con-
trol.
Components are sorted in the sort mode selected.
You can select any component for listening from the list of
sorted components.
1
Press the [MENU] button.
2
Turn the [ ] control to select Search
Mode and push the [ ] control.
3
Turn the [ ] control to select Sorted
List and push the [ ] control.
4
Turn the [ ] control to select a com-
ponent and push the [ ] control.
You can select any component from the sorted list.
Component Search Mode
Sorting Components
/
/
/
/
/
/
/
/
/
Sorted List Search Mode
/
/
/
/
/
/

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo CR-505DAB and is the answer not in the manual?

Onkyo CR-505DAB Specifications

Power Output IconPower Output
power output (DIN)20 W + 20 W (4 Ω, 1 kHz)
power output (JEITA)25 W + 25 W (4 Ω, 1 kHz)
dynamic power30 W + 30 W (4 Ω)
Total Harmonic Distortion IconTotal Harmonic Distortion
THD (AMP)0.2% (5 W Output, 4 Ω)
THD (FM Stereo)0.46% (1 kHz)
THD (FM Mono)0.4% (1 kHz)
THD (AM)1.60%
THD (DAB)0.20%
THD (CD)0.01%
Frequency Response IconFrequency Response
frequency response (AMP)10 Hz-50 kHz/+3 dB, –3 dB (LINE)
frequency response (FM)30 Hz-15 kHz/+1.5 dB, –1.5 dB
frequency response (DAB)20 Hz-20 kHz
frequency response (CD)20 Hz-20 kHz
General Specifications IconGeneral Specifications
power supplyAC 230-240 V, 50 Hz
power consumption75 W
stand-by power consumption1.0 W
dimensions (W x H x D)205 W x 103 H x 356 D mm
weight5.3 kg
