Onkyo DR-UN7 User Manual

51
Listening to the Radio—Continued
Repeatedly pressing DISPLAY on the remote controller or on the unit toggles between two types of information
display.
Switching the Display Information
DISPLAY
DISPLAY
FM/AM
Frequency
Preset channel name (*)
* If a given preset channel is not named, the unit displays
“No Name,” then indicates the frequency. see “Naming a
Preset Channel” on page 54.

Onkyo DR-UN7 Specifications

Power

power supply	AC 120 V, 60 Hz
power consumption	115 W
stand-by power consumption	0.2 W

Operating Environment

operating temperature	5 ˚C–35 ˚C
operating humidity	5 %–85 %
tuning frequency range	87.5 MHz–107.9 MHz

Audio Specifications

signal to noise ratio	100 dB (LINE, IHF-A)
frequency response	10 Hz–100 kHz/±3 dB (LINE)
total harmonic distortion	5 % (Power Rated)

Weight and Dimensions

dimensions	205 W x 147 H x 353 D mm
weight	5.4 kg
