Onkyo DR-UN7 User Manual

56
Enjoying Surround Sound
The DVD receiver will provide you a full-fledged home
theater, when it is added on extra speakers in addition to
the two front speakers. (For information about how to
add on, see page 25.)
The factory default settings support the two channels
with only a left and a right front speakers; you must con-
figure the settings according to the number of the speak-
ers you have added on.
Notes:
• After you have changed the number of the connected
speakers, you must configure the number, because the
surround effect is subject to change according to the
number of the combined speakers.
• If you want to abort the setting, press “RCV SETUP”.
Configuring Subwoofer and Setting
Up the Number of Speakers
1
Press RCV SETUP.
The display will show “1.Sp Config”.
2
Press ENTER.
The display will show “Subwfr :No”.
3
Press / to switch “Yes” and
“No”.
Yes: Deep bass will be output from a
subwoofer.
No: Deep bass will not be output from a
subwoofer.
Configure the output setting for a sub-
woofer to “No” when the output from it
is unneeded, even if it is connected.
4
Press / to select “Speaker:”.
RCV SETUP
RETURN
ENTER
/
/
5
Press / (repeatedly) to select
the number of the connected
speakers.
2ch: Only a left and a right front speak-
ers.
5ch: A center speaker and a left and a
right surround speakers in addition to a
left and a right front speakers.
6
Press RETURN.
Returns to the display shown in step 1.
Go to “Setting Distance of Speakers” at
page 57.

Onkyo DR-UN7 Specifications

Power

power supply	AC 120 V, 60 Hz
power consumption	115 W
stand-by power consumption	0.2 W

Operating Environment

operating temperature	5 ˚C–35 ˚C
operating humidity	5 %–85 %
tuning frequency range	87.5 MHz–107.9 MHz

Audio Specifications

signal to noise ratio	100 dB (LINE, IHF-A)
frequency response	10 Hz–100 kHz/±3 dB (LINE)
total harmonic distortion	5 % (Power Rated)

Weight and Dimensions

dimensions	205 W x 147 H x 353 D mm
weight	5.4 kg
