Onkyo DR-UN7 User Manual

70
Initial Settings menu
The Initial Settings menu provides audio and video out-
put settings, parental lock settings, and display settings,
among others.
If an option is grayed out it means that it cannot be
changed at the current time. This is usually because a
disc is playing. Stop the disc, then change the setting.
Notes:
• In the following table, the default setting is shown in
bold: other settings are shown in italics.
• Check the operating instructions supplied with your
other equipment to see which digital audio formats it’s
compatible with.
• Some settings, such as TV Screen, Audio Language
and Subtitle Language may be overridden by the DVD
disc. Often these settings can also be made from the
DVD disc menu.
Video Output settings
Note:
If visual image becomes invisible after you have set “Progressive” for “Component Out”, it is likely that the connected
TV does not support the progressive output. In this case, perform the following steps to return the setting to “Interlace”:
1 Stop DVD playback.
2 Press EDIT/NO/CLEAR.
3 Rotate MULTI JOG to select “Interlace?”.
4 Press MULTI JOG.
You will see the message “Waiting”. Then wait for a moment until the initial display appears. The video output changes
over to “Interlace”.
Using the Initial Settings menu
DVD SETUP
ENTER
1
Press DVD SETUP and select “Ini-
tial Settings”.
2
Use the cursor buttons and
ENTER to select the setting and
option you want to set.
All the settings and options are explained
on the following pages.
Setting Option What it means
TV Screen
(See also “Screen sizes
and disc formats” on
page 75.)
4:3 (Letter Box)
Set if you have a conventional 4:3 TV. Widescreen movies are
shown with black bars top and bottom.
4:3 (Pan & Scan)
Set if you have a conventional 4:3 TV. Widescreen movies are
shown with the sides cropped so that the image fills the
screen.
16:9 (Wide) Set if you have a widescreen TV.
Component Out
Progressive
Set if your TV is compatible with progressive scan video (see
your TV’s instruction manual for details).
Note that progressive scan video is only output from the com-
ponent video jacks.
Interlace Set if your TV is not compatible with progressive scan video.

Onkyo DR-UN7 Specifications

Power

power supply	AC 120 V, 60 Hz
power consumption	115 W
stand-by power consumption	0.2 W

Operating Environment

operating temperature	5 ˚C–35 ˚C
operating humidity	5 %–85 %
tuning frequency range	87.5 MHz–107.9 MHz

Audio Specifications

signal to noise ratio	100 dB (LINE, IHF-A)
frequency response	10 Hz–100 kHz/±3 dB (LINE)
total harmonic distortion	5 % (Power Rated)

Weight and Dimensions

dimensions	205 W x 147 H x 353 D mm
weight	5.4 kg
