Onkyo DR-UN7 User Manual

53
Changing the Preset Channels—Continued
Erasing a Preset Channel – Preset
Erase
1
Call the preset channel you wish
to erase.
2
Press EDIT/NO/CLEAR and turn
MULTI JOG until “PresetErase?”
appears in the display.
3
Press MULTI JOG.
A message requesting confirmation
appears in the display.
To stop erasing, press EDIT/NO/
CLEAR.
4
Press MULTI JOG.
“Complete” appears in the display. The
preset channel is erased.
2
2-4
Display

Onkyo DR-UN7 Specifications

Power

power supply	AC 120 V, 60 Hz
power consumption	115 W
stand-by power consumption	0.2 W

Operating Environment

operating temperature	5 ˚C–35 ˚C
operating humidity	5 %–85 %
tuning frequency range	87.5 MHz–107.9 MHz

Audio Specifications

signal to noise ratio	100 dB (LINE, IHF-A)
frequency response	10 Hz–100 kHz/±3 dB (LINE)
total harmonic distortion	5 % (Power Rated)

Weight and Dimensions

dimensions	205 W x 147 H x 353 D mm
weight	5.4 kg
