Onkyo FR-V77 User Manual

34
Various ways to play CDs and MDs
Five different playback modes are available in addition to normal playback. Insert
the CD or MD before you operate (see page 16 and 18).
MEMORY playback
You can select and store track numbers (up to 25) in
a desired playback order.
While the source is CD or MD, and in stop mode
1 Press MODE/AUTO/MONO
repeatedly until the MEMORY
indicator lights in the display.
2 Turn MULTI JOG to select the
first track you want to play back,
then press MULTI JOG.
The selected track is stored in memory.
To select the next track to be played,
repeat this step.
Advanced Operation
SLEEP SOURCE C D TIMER M D M D
CH
C D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
Track number to be
stored in memory
The total time of
programmed tracks
3 Press on the selected
source to start MEMORY
playback.
When the unit finishes playing the
track number you stored last, playback
stops. The track numbers stored in
memory are be retained.
The playing track number
SLEEP SOURCE C D TIMER M D M DM D
CHCH
C DC D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
To select a track number in memory
Turn MULTI JOG or press it repeatedly during MEMORY
playback.
To check the track numbers in memory
Press / while the CD/MD is stopped.
To erase a track number from memory
• While in MEMORY playback mode, and the CD/MD is
stopped, press EDIT/CLEAR/NO. Each press erases the
last track number stored in memory.
• If you change the playback mode, all data stored in
MEMORY playback will be erased.
Operating with the
remote controller
To select a track number in memory
Press / repeatedly during MEMORY playback.
To check the track numbers in memory
Press / while the CD/MD is stopped.
To erase a track number from memory
• While the unit is in MEMORY playback mode, and the CD/
MD is stopped, press CLEAR. Each press erases the last
track stored in memory.
• If you change the playback mode, all data stored in
MEMORY playback will be erased.
To cancel a track number stored in
memory
Press EDIT/CLEAR/NO. Each press erases
the last track number stored in memory.
Note
If the total playing time of the programmed
tracks exceeds the following time length,
the FR-V77 does not display the total time.
However, this does not affect MEMORY
playback.
CD: “--:--” appears when the total time
meets or exceeds 99 minutes 59 seconds.
MD: “---:--” appears when the total time
meets or exceeds 511 minutes 59 seconds.
“--:--” appears when you program 21 or
more tracks of a CD.
SLEEP SOURCE C D TIMER M D M D
CH
C D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
The MEMORY indicator lights.
PUSH TO ENTER
MULTI JOG
PUSH TO ENTER
MULTI JOG
3
3
2
1
/
EDIT/CLEAR/
NO
MODE
AUTO/MONO
REMOTE CONTROLLER
RC-433S
CD MD FM AM
S.BASS
TAPE FFTAPE REW
CD/MD/CDR
MODE
REPEAT
CLEAR
SCROLL
CD
MD
CDR
TAPE
MUTING
INPUT
1234
5678
9 10/0
V
O
L
U
M
E
U
P
V
O
L
U
M
E
D
O
W
N
--/---
Number buttons
See pages 17
and 19.
(These buttons do
not operate during
MEMORY
playback.)
Press on the
selected source.
CLEAR
/
/
2
3
1

Onkyo FR-V77 Specifications

Power

power supply	AC 220-230 V, 50/60 Hz
power consumption	63 W (220-230 V, 50/60 Hz)
power consumption (standby)	7 W
power consumption (energy save)	1.5 W

Amplifier Specifications

power output	2 × 26 W at 4 Ω EIAJ
total harmonic distortion	0.4 % at rated power
damping factor	25 at 8 Ω

CD Player

frequency response	10 Hz to 20 kHz (± 3 dB)
wow and flutter	Below threshold of measurability
signal readout system	Optical non-contact

MD Recorder

recording time	320 minutes maximum (at LP4 mode)
frequency response	10 Hz to 20 kHz (± 3 dB)
signal readout system	Optical non-contact

Tuner Specifications

tuning range	FM: 87.50 to 108.00 MHz
usable sensitivity	FM Mono: 11.2 dBf, 1.0 µV (75 Ω IHF)
signal to noise ratio	FM Mono : 73 dB IHF

Weight and Dimensions

dimensions	205 × 154 × 356 mm
weight	5.5 kg
