Onkyo FR-V77 User Manual

43
Combining selected tracks
– Combine
• This can be done only when an MD is playing,
paused, or stopped.
• When the preceding track has a name, this name
will be used as the name of the combined track.
• To cancel the operation, press MD .
1 Insert the MD, then select MD as
the source.
Use a recordable MD with the record-
protect window closed.
2 Turn MULTI JOG to select the
track to be combined.
The selected track will be combined
with the preceding track, so it is
impossible to select the first track.
3 Press EDIT/CLEAR/NO
repeatedly until “Combine?”
appears in the display.
4 Press REPEAT/YES.
The selected and preceding tracks are
displayed.
5 Press REPEAT/YES.
“Rehearsal” and “Track OK?” appear
alternatively and an approximately
eight-second section around the
combining point is played repeatedly.
6 Press REPEAT/YES to combine.
“Complete” appears.
The selected and preceding tracks are
combined and all tracks are
renumbered from the top.
Combining the selected and preceding
tracks
Renumbering the tracks
SLEEP SOURCE C D TIMER M D M D
CH
C D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
The selected
track
Approximately eight seconds
rehearsal play
The selected track
The combining point
The preceding track
The preceding
track
SLEEP SOURCE C D TIMER M D M D
CH
C D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
1 2 34
145
14523
SLEEP SOURCE C D TIMER M D M D
CH
C D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
SLEEP SOURCE C D TIMER M D M D C D
C D
ONCE
W.DAY
W.END
REC
L
R
S.BASS
-
40
-
20
-
10 0 OVER
-
6
-
2
MUTING DIGITAL CHAIN
REPEAT
DISC TRACK ELAPSED REMAIN TITLE
RDS MONO AUTO STEREO TUNED
1 TR MEMORY
RANDOM
LEVEL - SYNC
-
M D
DUB TOC
CH
PUSH TO ENTER
MULTI JOG
1
1
2
3
4, 5, 6
CD/MD
EDIT / CLEAR
NO
REPEAT
YES
REPEAT
YES
REPEAT
YES

Onkyo FR-V77 Specifications

Power

power supply	AC 220-230 V, 50/60 Hz
power consumption	63 W (220-230 V, 50/60 Hz)
power consumption (standby)	7 W
power consumption (energy save)	1.5 W

Amplifier Specifications

power output	2 × 26 W at 4 Ω EIAJ
total harmonic distortion	0.4 % at rated power
damping factor	25 at 8 Ω

CD Player

frequency response	10 Hz to 20 kHz (± 3 dB)
wow and flutter	Below threshold of measurability
signal readout system	Optical non-contact

MD Recorder

recording time	320 minutes maximum (at LP4 mode)
frequency response	10 Hz to 20 kHz (± 3 dB)
signal readout system	Optical non-contact

Tuner Specifications

tuning range	FM: 87.50 to 108.00 MHz
usable sensitivity	FM Mono: 11.2 dBf, 1.0 µV (75 Ω IHF)
signal to noise ratio	FM Mono : 73 dB IHF

Weight and Dimensions

dimensions	205 × 154 × 356 mm
weight	5.5 kg
