Onkyo HT-R508 User Manual

30
Connecting Your Components —Continued
■ RI Dock with video
Connect your RI Dock’s analog audio output jacks
and S-Video output jack to the AV receiver’s
CBL/SAT IN L/R jacks and CBL/SAT IN S jack.
■ RI Dock without video
Connect your RI Dock’s analog audio output jacks to
the AV receiver’s TAPE IN L/R jacks (
1
).
Notes:
• Connect the Remote Interactive Dock with an
cable (see page 31).
• Set the Remote Interactive Dock’s RI MODE switch
to HDD or HDD/DOCK.
• Set the AV receiver’s Input Display to DOCK (see
page 37).
• Refer to the Remote Interactive Dock’s instruction
manual.
(DS-A1 hookup shown here.)
•With connection , you can use functions.
•To connect the recorder digitally, use connections and , or and .
Connecting an RI Dock
OUT
OUT
CBL/SAT IN
IN IN
IN
IN
IN
IN IN
VCR/DVR IN DVD IN
OUT
COMPONENT VIDEO
Y
C
B/PB
CR/PR
IN 1IN 2
OUT
ANTENNA
FM
AM
75
FRONT SURROUN
D
CD
R R
LL
TAPE
OUT
CBL/SAT
CBL/SAT
VCR/DVR
VCR/DVR
DVD
DVD
R
L
S
V
MONITO
R
OUT
S
V
REMOTE
CONTROL
HDMI
ASSIGNABLE
ASSIGNABLE
COAX-
IAL
OPTICAL
1
(DVD)
2
(CBL/SAT)
1
(VCR/DVR)
2
(CD)
DIGITAL IN
AUDIO
OUT
LR
S VIDEO
OUT
1
Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Connection AV receiver Signal flow Cassette/CDR/MD/DAT recorder
TAPE IN L/R
TAPE OUT L/R
⇐
⇒
Analog audio L/R output
Analog audio L/R input
DIGITAL IN COAXIAL 2
⇐
Digital coaxial output
DIGITAL IN OPTICAL 1
⇐
Digital optical output
HDMI
ASSIGNABLE
ASSIGNABLE
COAX-
IAL
OPTICAL
1
(DVD)
2
(CBL/SAT)
1
(VCR/DVR)
2
(CD)
DIGITAL IN
OUT
OUT
OUT
CBL/SAT IN
IN IN
IN
IN
IN
IN IN
VCR/DVR IN DVD IN
OUT
COMPONENT VIDEO
Y
C
B/PB
CR/PR
IN 1IN 2
OUT
ANTENNA
FM
AM
75
SUB
WOOFER
FRONT SURROUND CENTER
CD
R R
LL
TAPE
CBL/SAT
CBL/SAT
VCR/DVR
VCR/DVR
DVD
DVD
R
L
S
V
MONITOR
OUT
S
V
REMOTE
CONTROL
OPTICAL
1
(VCR/DVR)
2
(CBL/SAT)
COAX-
IAL
OUT
REC PLAY
IN OUT
L
R
L
R
IN
TAPE
L
R
OPTICAL
OUT
COAXIAL
OUT
b
c
a
Step 1:
Choose a connection that matches the recorder ( , , or ), and then make the connection.
a b c
Cassette recorder, CDR, etc.
Connect one or the
other
These connections
must be assigned
(see page 37)
a
a b a c
a
b
c
HT-R508En.book Page 30 Wednesday, March 14, 2007 10:12 AM

Onkyo HT-R508 Specifications

Amplifier Section

rated output power (FTC)	110 watts
rated output power (IEC)	5 ch × 130 W
maximum output power (JEITA)	5 ch × 160 W
dynamic power (3Ω, 1 ch driven)	210 W
dynamic power (4Ω, 1 ch driven)	190 W
dynamic power (8Ω, 1 ch driven)	130 W
total harmonic distortion (THD)	0.08%
damping factor	60
input sensitivity and impedance	200 mV/ 47 kΩ
output level and impedance	200 mV/ 470 Ω
frequency response	5 Hz–100 kHz
tone control (bass)	±10 dB, 50 Hz
tone control (treble)	±10 dB, 20 kHz
signal to noise ratio	100 dB
speaker impedance	8Ω–16Ω

Video Section

input sensitivity/output level and impedance (component and s-video y)	1 Vp-p /75Ω
input sensitivity/output level and impedance (component pb/cb, pr/cr)	0.7 Vp-p /75Ω
input sensitivity/output level and impedance (s-video c)	0.28 Vp-p /75Ω
input sensitivity/output level and impedance (composite)	1 Vp-p /75Ω
component video frequency response	5 Hz – 50 MHz

Tuner Section

fm tuning frequency range	87.5 MHz– 108.0 MHz
am tuning frequency range	522 kHz–1611 kHz
radio presets	40

General

power supply	AC 230 V, 50 Hz
power consumption	560 W
standby power consumption	0.3 W
dimensions (W × H × D)	435 × 150 × 377 mm
weight	10.2 kg
