Onkyo HT-R508 User Manual

64
SN 29344418
I0702-1
(C) Copyright 2007 ONKYO CORPORATION Japan. All rights reserved.
http://www.onkyo.com/
HOMEPAGE
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8124
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452
ONKYO CHINA LIMITED
Unit 1&12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung,
N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039
http://www.ch.onkyo.com/
* 2 9 3 4 4 4 1 8 *
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Rated Output Power (FTC)
All channels: 110 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven at 1 kHz, with a maximum total
harmonic distortion of 0.9%
Rated Output Power (IEC)
5 ch
× 130 W at 8 ohms, 1 kHz, 1 ch
driven
Maximum Output Power (JEITA)
5 ch
× 160 W at 8 ohms, 1 kHz, 1 ch
driven
Dynamic Power 210 W (3
Ω , 1 ch driven)
190 W (4
Ω , 1 ch driven)
130 W (8
Ω , 1 ch driven)
THD (Total Harmonic
Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1kHz, 8
Ω )
Input Sensitivity and
Impedance 200 mV/ 47 k
Ω (LINE)
Output Level and
Impedance 200 mV/ 470
Ω (REC OUT)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB (Direct mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 8
Ω –16 Ω
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75
Ω (Component and S-Video Y)
0.7 Vp-p /75
Ω (Component P B /C B , P R /C R )
0.28 Vp-p /75
Ω (S-Video C)
1 Vp-p /75
Ω (Composite)
Component Video
Frequency Response 5 Hz – 50 MHz
FM Tuning Frequency Range 87.5 MHz– 108.0 MHz
AM Tuning Frequency Range 522 kHz–1611 kHz
Radio Presets 40
Power Supply AC 230 V, 50 Hz
Power Consumption 560 W
Standby Power
Consumption 0.3 W
Dimensions
(W
× H × D) 435 × 150 × 377 mm
Weight 10.2 kg
HDMI IN1, IN2
Component DVD, VCR/DVR, CBL/SAT
S-Video DVD, VCR/DVR, CBL/SAT
Composite DVD, VCR/DVR, CBL/SAT, AUX
HDMI OUT
Component OUT
S-Video MONITOR, VCR/DVR
Composite MONITOR, VCR/DVR
Digital Inputs Optical: 2
Coaxial: 2
Analog Inputs DVD (MULTICHANNEL), VCR/DVR,
CBL/SAT, AUX, TAPE, CD
Multichannel Inputs 5.1 (DVD)
Analog Outputs TAPE, VCR/DVR
Subwoofer Pre Outputs 1
Speaker Outputs L, R, C, SL, SR
Phones 1
HT-R508En.book Page 64 Wednesday, March 14, 2007 10:12 AM

Onkyo HT-R508 Specifications

Amplifier Section

rated output power (FTC)	110 watts
rated output power (IEC)	5 ch × 130 W
maximum output power (JEITA)	5 ch × 160 W
dynamic power (3Ω, 1 ch driven)	210 W
dynamic power (4Ω, 1 ch driven)	190 W
dynamic power (8Ω, 1 ch driven)	130 W
total harmonic distortion (THD)	0.08%
damping factor	60
input sensitivity and impedance	200 mV/ 47 kΩ
output level and impedance	200 mV/ 470 Ω
frequency response	5 Hz–100 kHz
tone control (bass)	±10 dB, 50 Hz
tone control (treble)	±10 dB, 20 kHz
signal to noise ratio	100 dB
speaker impedance	8Ω–16Ω

Video Section

input sensitivity/output level and impedance (component and s-video y)	1 Vp-p /75Ω
input sensitivity/output level and impedance (component pb/cb, pr/cr)	0.7 Vp-p /75Ω
input sensitivity/output level and impedance (s-video c)	0.28 Vp-p /75Ω
input sensitivity/output level and impedance (composite)	1 Vp-p /75Ω
component video frequency response	5 Hz – 50 MHz

Tuner Section

fm tuning frequency range	87.5 MHz– 108.0 MHz
am tuning frequency range	522 kHz–1611 kHz
radio presets	40

General

power supply	AC 230 V, 50 Hz
power consumption	560 W
standby power consumption	0.3 W
dimensions (W × H × D)	435 × 150 × 377 mm
weight	10.2 kg
