21
1.Input/Output Assign
Monitor Out
The video input signals input to the unit will be converted when they are output from the
HDMI OUT jack to the TV so that their resolution can match that of the TV used.
Setting item Default Value Setting Details
Monitor Out MAIN Select the HDMI jack to be connected with the
T V.
"MAIN": When connecting the TV to the HDMI
OUT MAIN jack
"SUB": When connecting the TV to the HDMI
OUT SUB jack
• The resolution of the input signal does not
change when output through HDMI OUT
SUB jack.
"MAIN+SUB": When connecting to both the
MAIN and SUB jacks
• Video signals input to the composite video
input jack or the COMPONENT VIDEO input
jacks will be upconverted to HDMI signals
and then output from the HDMI output jack.
• If "MAIN+SUB" is selected
– Only "Through" or "Auto" can be selected
in "Resolution".
– The resolution of the input signal does not
change when output through HDMI OUT
SUB jack.
• HDCP2.2 protected video from HDMI OUT
SUB will not be displayed.
Setting item Default Value Setting Details
Resolution Through Specify the output resolution of the HDMI OUT
jacks. The image resolution of the unit will be
converted so that it can match the resolution
supported by the TV used.
"Through": The output resolution will be the
same as that of the input signals.
"Auto": The resolution will automatically be
converted according to the resolution supported
by the TV.
"480p (480p/576p)", "720p", "1680×720p",
"1080i", "1080p", "2560×1080p": Select the
desired resolution.
"4K": About four times as high resolution
as 1080p (3840×2160 or 4096×2160 pixels
depending on the resolution supported by the
connected TV)
• If "1080p" is selected, 1080p/24 input signals
will be output with an unchanged resolution.
• If the selected resolution is not supported
by the monitor, the video is displayed in the
same resolution as the input signal.
• If "4K" is selected, video signals may not
be output to some types of TV. For details,
see "Regarding the Video Resolution" in
"Troubleshooting".
• If "Monitor Out" is set to "SUB", this setting
will be set to "Through".
• Press ENTER if you output signals from the
HDMI OUT MAIN jack and check the video
on the TV while making this setting. Press
RETURN if no video is displayed. (except
when "NET", "USB" or "BLUETOOTH" is
selected)
To Next Page
