27
Level Calibration
Adjust the level of each speaker with the built-in test tone. Settings are automatically
configured if you use the Automatic Speaker Setup.
Setting item Default Value Setting Details
Front Left 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Center 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Front Right 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Surround Right 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Back Right 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Back Left 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Surround Left 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Subwoofer 0 dB Select a value between "-15 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Height Left 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
Height Right 0 dB Select a value between "-12 dB" to "+12 dB". A
test tone will be output each time you change
the value. Select the desired level.
• In the following cases, the settings for "Level Calibration" cannot be changed:
– The speaker is set to "No" or "None" in "Speaker Configuration".
– Mute (MUTING) is set.
3.Audio Adjust
Configure various settings related to sound, such as settings for listening to multiplex audio
or multilingual TV broadcasts and sound field settings for listening modes.
Multiplex/Mono
Setting item Default Value Setting Details
Multiplex
Input Channel
Main Set the audio channel or language to be output
when playing multiplex audio or multilingual TV
broadcasts etc.
"Main": Main channel only
"Sub": Sub channel only
"Main/Sub": Main and sub channels will be
output at the same time.
• If multiplex audio is being played, "1+1" will
be displayed when DISPLAY is pressed.
Mono
Input Channel
Left+Right Set the input channel to use for playing any 2
ch digital source such as Dolby Digital, or 2-ch
analog/PCM source in the Mono listening mode.
"Left": Left channel only
"Right": Right channel only
"Left + Right": Left and right channels
Dolby
Make the settings for Dolby listening mode.
Setting item Default Value Setting Details
PLIIx Music
(2ch Input)
Panorama
Off Adjust the sound field setting for playing any
2 ch digital source such as Dolby Digital or 2
ch analog/PCM source in the Dolby PrologicII
Music listening mode. Select the width of sound
field.
"On": Width of sound field will be increased.
"Off": Default value
To Next Page
