Onkyo TX-NR636 User Manual

Advanced Settings
24
2.Speaker Setup
Allows you to change the speaker configuration such as existence of subwoofer, crossover
frequency, and so on. Settings are automatically configured if you use the Automatic
Speaker Setup.
Furthermore, you will not be able to select this setting if you have a pair of headphones
connected or you are listening through your TV speakers.
Speaker Settings
Change the impedance of the connected speakers, the type of front speaker connection,
and other speaker settings.
Setting item Default Value Setting Details
Speaker
Impedance
(European,
Australian and
Asian models)
6ohms Set the impedance of the connected speakers.
"4ohms": When any of the connected speakers
have4Ωormoretolessthan6Ωimpedance
"6ohms": When the connected speakers all have 6
Ωormoreimpedance
Front Speakers
Type
Normal Select the type of front speaker connection.
"Normal": When front speakers are connected in a
normal manner
"Bi-Amp": When front speakers are bi-amp
connected
Powered Zone 2 No Set presence of speaker terminal connection of
Zone 2
"Yes": When speakers are connected to ZONE2
speaker terminals
"No": When speakers are not connected to ZONE2
speaker terminals
• If "Front Speakers Type" is set to "Bi-Amp", this
setting will be set to "No".
• For impedance, check the indications on the back of the speakers or their instruction manual.
Speaker Configuration
Allows you to change the speaker configuration such as presence or not of each speaker,
crossover frequency, and so on. Settings are automatically configured if you use the
Automatic Speaker Setup. Audio will not be output while you are making this setting.
Setting item Default Value Setting Details
Subwoofer Ye s Set whether a subwoofer is connected or not.
"Yes": When subwoofer is connected
"No": When subwoofer is not connected
Front 100Hz Select the frequency to start outputting bass
frequencies (crossover frequency) for each
channel from "40Hz" to "200Hz".
"Full Band": Full band will be output.
"None": When no compatible speaker is connected
• "Front" will be fixed to "Full Band" if "Subwoofer"
is set to "No", and the bass frequencies of the
other channels will be output from the front
speakers. To make the settings, refer to the
instruction manual of the speakers used.
Center
100
Hz
Select the frequency to start outputting bass
frequencies (crossover frequency) for each
channel from "40Hz" to "200Hz".
"Full Band": Full band will be output.
"None": When no compatible speaker is connected
• This setting cannot be set to "Full Band" unless
"Front" is set to "Full Band".
Surround
100
Hz
Select the frequency to start outputting bass
frequencies (crossover frequency) for each
channel from "40Hz" to "200Hz".
"Full Band": Full band will be output.
"None": When no compatible speaker is connected
• This setting cannot be set to "Full Band" unless
"Front" is set to "Full Band".

Onkyo TX-NR636 Specifications

General

Channels	7.2
Frequency Response	5 Hz-100 kHz/+1 dB, -3 dB (Direct Mode)
HDMI Inputs	7
HDMI Outputs	2
Dolby Atmos	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Pass-Through	Yes
Weight	23.1 lbs (10.5 kg)
Network Connectivity	Ethernet, Wi-Fi
Rated Output Power (1kHz, 1 channel driven)	160 W (6 ohms, 1 kHz, 1 channel driven, JEITA)
THD+N (Total Harmonic Distortion + Noise)	0.08% (20 Hz - 20 kHz, half power)
Input Sensitivity and Impedance	200 mV/47 kΩ
Tone Control	±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio	100 dB (Line, IHF-A)
Speaker Impedance	4 - 16 Ohms
Video Input Sensitivity and Impedance	1 Vp-p/75 Ω
Component Video Frequency Response	5 Hz-60 MHz/+0 dB, -3 dB
HDMI Support	4K/60 Hz, HDCP 2.2
DTS:X	No
Dimensions	435 x 173.5 x 329 mm
Audio Inputs	2 Digital Audio (Optical and Coaxial)
Supported Audio Formats	MP3, WMA, WAV, AAC, FLAC, ALAC
Supported Video Formats	4K/60 Hz, 3D
Power Output per Channel	160 W (6 ohms, 1 kHz, 1 channel driven, JEITA)
