Onkyo TX-NR636 User Manual

Advanced Settings
29
DTS
Make the settings for DTS Neo:6 Music listening mode.
Setting item Default Value Setting Details
Neo:6 Music
Center Image
2 Adjust the width of the sound field of the front
channel when playing in the DTS Neo:6 Music
listening mode.
"0" to "5": Selecting a smaller value brings the
sound field of the front channel to the center
while selecting a larger value spreads the sound
field of the front channel to left and right.
Theater-Dimensional
Make the settings for Theater-Dimensional mode.
Setting item Default Value Setting Details
Listening Angle Wide Set the angle of the front left and right speakers
relative to the listening position when playing in
the Theater-Dimensional listening mode.
"Narrow": Less than 30°
"Wide": Greater than 30°
• Values recommended for "Listening Angle" are: 20° when "Narrow" is selected and 40° when "Wide"
is selected.
4.Source Setup
Adjust the volume level difference among the multiple devices connected to this unit,
rename an input selector, or adjust the image quality. The setting can be separately set to
each input selector button. When you select a desired input to check the video or audio,
start playback of the connected device.
AccuEQ Room Calibration
Setting item Default Value Setting Details
AccuEQ Room
Calibration
Off Enable/disable the sound field set in automatic
speaker setup
"On": Enable this function
"Off": Disable this function
• In the following cases, the setting cannot be
changed:
– Automatic speaker setup is not performed.
– Headphones are connected.
IntelliVolume
Setting item Default Value Setting Details
IntelliVolume 0 dB Adjust the volume level difference between the
devices connected to the unit. Select a value
between "-12 dB" to "+12 dB". Set a negative
value if the volume of the target device is larger
than the others and a positive value if smaller.
• This function is not effective in Zone 2.

Onkyo TX-NR636 Specifications

General

Channels	7.2
Frequency Response	5 Hz-100 kHz/+1 dB, -3 dB (Direct Mode)
HDMI Inputs	7
HDMI Outputs	2
Dolby Atmos	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Pass-Through	Yes
Weight	23.1 lbs (10.5 kg)
Network Connectivity	Ethernet, Wi-Fi
Rated Output Power (1kHz, 1 channel driven)	160 W (6 ohms, 1 kHz, 1 channel driven, JEITA)
THD+N (Total Harmonic Distortion + Noise)	0.08% (20 Hz - 20 kHz, half power)
Input Sensitivity and Impedance	200 mV/47 kΩ
Tone Control	±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio	100 dB (Line, IHF-A)
Speaker Impedance	4 - 16 Ohms
Video Input Sensitivity and Impedance	1 Vp-p/75 Ω
Component Video Frequency Response	5 Hz-60 MHz/+0 dB, -3 dB
HDMI Support	4K/60 Hz, HDCP 2.2
DTS:X	No
Dimensions	435 x 173.5 x 329 mm
Audio Inputs	2 Digital Audio (Optical and Coaxial)
Supported Audio Formats	MP3, WMA, WAV, AAC, FLAC, ALAC
Supported Video Formats	4K/60 Hz, 3D
Power Output per Channel	160 W (6 ohms, 1 kHz, 1 channel driven, JEITA)
