Connecting speakers
You can select the layout of speakers to be installed from various patterns when using this unit. Use the following ow chart to select the speaker layout that suits your
speakers and usage environment. You can check the connection method and default settings. Dolby Atmos ( p106) listening mode faithfully reproduces the sound
design recorded in the Dolby Atmos audio format by installing Surround Back Speakers or Height Speakers. Dolby Atmos enables the accurate placement of sound
objects that have independent motion in a three-dimensional space with even greater clarity.
Yes No
Do you enjoy sound with Dolby Atmos?
 When using Surround Back
Speakers
• 7.1 Channel System (
p45)
• 7.1 Channel System + ZONE
SPEAKER ( p46)
• 7.1 Channel System (Bi-Amping
the Speakers) ( p47)
 When using 1 set of Height Speakers
• 5.1.2 Channel System ( p48)
• 5.1.2 Channel System + ZONE
SPEAKER ( p49)
• 5.1.2 Channel System (Bi-Amping
the Speakers) ( p50)
• 7.1.2 Channel System ( p51)
• 7.1.2 Channel System + ZONE
SPEAKER ( p52)
 When using 2 sets of Height Speakers
• 5.1.4 Channel System ( p53)
• 5.1.4 Channel System + ZONE
SPEAKER ( p54)
• 7.1.4 Channel System ( p55)
• 7.1.4 Channel System + ZONE
SPEAKER ( p56)
• 5.1 Channel System ( p42)
• 5.1 Channel System + ZONE
SPEAKER ( p43)
• 5.1 Channel System (Bi-Amping
the Speakers) ( p44)

Onkyo TX-RZ730 Specifications

General

Package depth	468 mm
Package width	570 mm
Package height	288 mm
AirPlay	Yes
Display	-
HDCP version	2.2
Product color	Silver
Audio decoders	DTS-HD, DTS:X, Dolby Atmos, Dolby TrueHD
Cables included	AC
Package weight	13500 g
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	760 W
Card reader integrated	No
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
Connectivity technology	Wired & Wireless
12V trigger ports quantity	1
Speakers connectivity type	Banana connector
Number of HDMI outputs	2
HDMI in	7
Audio (L/R) in	6
Multichannel audio input type	RCA
Receiver type	stereo
Pre-out channels	7.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	250 W
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	175 W

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	177 mm
Weight	10800 g
