Onkyo TX-RZ730 User Manual

79
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Spotify
By connecting this unit to the same network as mobile devices, such as a smartphone and tablet, you can enjoy music played with Spotify Connect wirelessly.
• To play Spotify Connect, install a Spotify application on your smartphone or tablet. Also, you need to obtain a Spotify premium account.
– For details of Spotify settings, go to:
www.spotify.com/connect/
Playing Back
1. Connect the mobile device to the access point where this unit is connected via
network.
2. Start up the Spotify application.
3. Play a track on the Spotify application, switch the screen to the playback
operation screen, and then tap "Devices Available" on the bottom of the
screen.
4. Select this unit.
5. This unit is automatically turned on, the input is switched to NET, and Spotify
will start the streaming playback.
• When "5. Hardware" - "Power Management" - "Network Standby" is set to "O󰀨"
in the Setup menu, turn this unit on manually, and press NET on the remote
controller. In the factory default setting, the Network Standby function
( p144) is set to On.
Notes when using the multi-zone function
• To enjoy Spotify music in a separate room, select NET manually as the input
of the separate room. Then, select this unit on the Spotify application.
• Volume adjustment with the Spotify application is possible for speakers
connected to the ZONE speaker terminals or when the volume of the audio
device in a separate room is congured so that its volume can be adjusted on
this unit. In any other cases, adjust the volume on the audio device placed in a
separate room.
• To enjoy Spotify music in the main room after playing it in a separate room,
switch the input of the main room to NET.
Wi-Fi
Onkyo TX-RZ730 XXX
Devices Available
Devices Available

Onkyo TX-RZ730 Specifications

General

Package depth	468 mm
Package width	570 mm
Package height	288 mm
AirPlay	Yes
Display	-
HDCP version	2.2
Product color	Silver
Audio decoders	DTS-HD, DTS:X, Dolby Atmos, Dolby TrueHD
Cables included	AC
Package weight	13500 g
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	760 W
Card reader integrated	No
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Audio formats supported	AIFF, ALAC, DSD, FLAC, WAV
Connectivity technology	Wired & Wireless
12V trigger ports quantity	1
Speakers connectivity type	Banana connector
Number of HDMI outputs	2
HDMI in	7
Audio (L/R) in	6
Multichannel audio input type	RCA
Receiver type	stereo
Pre-out channels	7.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	250 W
Dynamic power per channel (4 Ohm)	220 W
Dynamic power per channel (8 Ohm)	130 W
Power output per channel (20-20KHz@8 Ohm)	175 W

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	177 mm
Weight	10800 g
