Onkyo TX-SR494 User Manual

61
Setup
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Setup Menu
Menu list
You can congure advanced settings to have a more enjoyable experience with this unit. For operation details, refer to "Menu operations". ( p63)
1. Input/Output
Assign
1. TV Out / OSD Make settings for TV output and On-Screen Displays (OSD) that appear on the TV. p64
2. HDMI Input Change input assignment between the input selectors and HDMI IN jacks. p65
3. Digital Audio Input Change input assignment between the input selectors and DIGITAL IN COAXIAL/OPTICAL jacks. p66
4. Analog Audio Input Change input assignment between the input selectors and AUDIO IN jacks. p66
2. Speaker 1. Conguration Change the settings of connection environment of the speakers. p67
2. Crossover Change the settings of crossover frequencies. p67
3. Distance Set the distance from each speaker to the listening position. p68
4. Level Calibration Adjust the volume level of each speaker. p69
5. Dolby Enabled
Speaker
Change the settings of Dolby Enabled Speakers. p69
6. Speaker Virtualizer The Speaker Virtualizer function can be switched between On and O󰀨. p69
3. Audio Adjust 1. Multiplex/Mono Change the settings of multiplex audio playback. p70
2. Dolby Change the setting of when Dolby signals are input. p70
3. DTS Change the setting of when DTS signals are input. p70
4. LFE Level Set the low-frequency e󰀨ect (LFE) level for Dolby Digital series, DTS series, Multichannel PCM,
and DSD signals.
p70
5. Volume Change the Volume settings. p71
4. Source 1. IntelliVolume Adjust the volume level when there are di󰀨erences in volume level among multiple devices
connected to this unit.
p71
2. Name Edit Set an easy name for each input. p71
Audio Select Select the priority for input selection when multiple audio sources are connected to one input
selector.
p72
Video Select When "TUNER" or "BLUETOOTH" input is selected, you can set the input from which video is
displayed on the TV.
p72

Onkyo TX-SR494 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
4Ω speaker support	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	109 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Audio (L/R) in	3
Digital audio optical in	1
Component video (YPbPr/YCbCr) in	0
Audio (L/R) out	8
Connectivity technology	Wired
Speakers connectivity type	Banana connector/Binding posts
Wi-Fi	No
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
AirPlay	-
Display	LCD
HDCP version	2.2
Product color	Black
Audio decoders	DTS Virtual:X, Dolby Atmos
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	490 W
THX-certified	THX

Weight and Dimensions

Depth	328 mm
Width	435 mm
Height	160 mm
Weight	10500 g
