ZS3-2 Controller Hardware Overview
TABLE 24
ZS3-2 Controller Physical Specifications
Dimension Measurement Dimension Measurement
Height 3.44 in./87.4 mm Depth 20.25 in./514 mm
Width 17.52 in./445 mm Weight 41.23 lb/18.70 kg
ZS3-2 Electrical Specifications - The ZS3-2 controller electrical specifications are listed
below. The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
■
Two C13 connectors which work on 110-220v outlets
Input
■
Nominal frequencies: 50/60Hz (47 to 63 Hz range)
■
Nominal voltage range: 100 to 120/200 to 240 VAC
■
Maximum current AC RMS: 6.8 A @ 100-120 V / 3.4 A @ 200-240 V
■
AC operating range: 90-264 VAC
Output
■
3.3 VDC STBY: 3.0A
■
+12 VDC: 86.7A
Power Dissipation
■
Max power consumption: 890 W max
■
Max heat output: 3026 BTU/hr
■
Volt-Ampere rating: 908 VA @ 240 VAC, 0.98P.F.
ZS3-2 Acoustic Noise Emissions - In compliance with the requirements defined in ISO 7779,
the workplace-dependent noise level of this product is less than 70 db (A).
ZS3-2 Internal Components
The ZS3-2 chassis has the following field replaceable units (FRUs). FRUs are not customer-
serviceable and must be replaced by trained Oracle service technicians.
■
PCIe Risers - There are three risers per system, each attached to the rear of the
motherboard. Each riser supports two PCIe cards (which are customer replaceable units
(CRUs).
162 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
