Orbit WaterMaster 57194 User Manual

TABLE OF CONTENTS
ENGLISH
Section One: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section Two: Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Section Three: Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Section Four: Manual Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Section Five: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Trouble-Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
The information in this manual is primarily intended for the user who will establish a
watering schedule and enter that schedule into the Controller. This product is intend-
ed to be used as an automatic timer controller for activating 24 VAC irrigation valves,
as described in this manual.
Help: Before returning this timer to the store, contact Orbit
®
Technical Service at:
Orbit
®
Technical Service: 1-800-488-6156 or 801-299-5555
Trademark Notice
WaterMaster
®
is a registered trademark of Orbit
®
Irrigation Products, Inc.
