Oriental motor BLE2D120-A User Manual

Operating using external signals
28

Procedures to set the rotation speed with an analog setting device
When the rotation speed is set using the external potentiometer or external DC voltage, the setting of the “Speed, torque limiting
command selection" parameter is required to change.
DC power supply
0-5 VDC
CN5
Pin No.13
Pin No.14
CN5
1
3
2
1
Check the connection
2
3
Press three
times
Press twice
4
5
Press
6
Turn
clockwise
to select 2
7
8
9
Press
ID input screen
Execute
Parameter mode
[ Parameter setting range ]
0: Digital setting
1: Analog setting for the rotation speed of the operation data No.1
2: Analog setting
Turn clockwise
to select 1820
Change the setting of the "Speed, torque limiting command selection" parameter (ID: 1820) to "1"
Set the rotation speed
Press once
Turn clockwise
to select
Conguration
Press twice
10
Turn on the AC power supply
PAVR2-20K
LOW
HIGH
Pin No.13 VM input
Pin No.12 VH input
Pin No.14 VL input
External potentiometer
0 to 20
kΩ
500
1000
1500
2000
2500
3000
3500
4000
0
PAVR2-20K (scale)
Motor shaft rotation speed (r/min)
Rotation speed: 0 r/min
External DC voltage (V)
Motor shaft rotation speed (r/min)
•
External DC voltage - Rotation speed characteristics
(representative values)
0
500
1000
1500
2000
2500
3000
3500
4000
24135
•
External potentiometer - Rotation speed characteristics
(representative values)
Changing the parameter can set the rotation
speed using DC voltage of 0 VDC to 10 VDC.
[ To return to the rotation speed display ]
Press
Press
three times
Details of parameters
⇒
USER MANUAL
When the operation input signal is turned ON, the motor rotates. Refer to p.27 for the operating method.
