Regulations and standards
Some products are recognized by UL under the UL and CSA Standards.
Products in this manual are axed the CE Marking under the Low Voltage Directive and EMC Directive.
Model
UL Standards, CSA
Standards
Republic of Korea,
Radio Waves Act
CE Marking
BLE2D30-A
,
BLE2D30-C
,
BLE2D60-A
,
BLE2D60-C
BLE2D120-A
,
BLE2D120-C
,
BLE2D200-C
BLE2D300-C
,
BLE2D400-S
○ ○ ○
BLE2D120-AM
,
BLE2D120-CM
,
BLE2D200-CM
× ×
○
1. UL Standards, CSA Standards
Applicable Standards Certication body Standards File No.
UL 61800-5-1
CSA C22.2 No.274
UL E171462
2. EU Directives

CE Marking
z
Low Voltage Directive
Applicable standards EN 61800-5-1
Installation conditions
(EN Standards)
For incorporating in equipment
Overvoltage category:
Ⅱ
Pollution degree: 2
Degree of protection: IP20
Protection against electric shock: Class
Ⅰ
equipment
•
This product is designed and manufactured to be incorporated in equipment.
•
This product cannot be used in IT power distribution systems.
•
Install the product inside an enclosure in order to avoid contact with hands.
•
Be sure to ground (protective earth) if the product can be made contact with hands. Ground the Protective Earth Terminals for
the motor (or connection cable) and driver securely.
•
Isolate power cables such as the connection cable, power supply cable and other drive cables from the signal cable (CN5) and
USB cable by means of double insulation.
z
EMC Directive
This product has received EMC compliance under the conditions specied in“Example of installation and wiring” on p.50. The
nal level of conformance of your mechanical equipment to the EMC Directive will vary depending on such factors as the control
system equipment used with the motor and driver, conguration of electrical parts, wiring, layout and hazard level. It therefore
must be veried through conducting EMC measures on your mechanical equipment.
Applicable standards
EMI
EN 55011 group1 classA
EN 61000-6-4, EN 61800-3
EMS EN 61000-6-2, EN 61800-3
Caution: This equipment is not intended for use in residential environments nor for use on a low-voltage public network
supplied in residential premises, and it may not provide adequate protection to radio reception interference in such
environments.
3. Republic of Korea, Radio Waves Act
KC Mark is axed to this product under the Radio Waves Act, the republic of Korea.
4. RoHS Directive
The products do not contain the substances exceeding the restriction values of RoHS Directive (2011/65/EU).
