Reference
−42−
12.3 Specications
•
o
in the motor model name indicates a code or number representing the gear ratio, the motor type, or the motor shaft type.
•
The value in a state where the gearhead is not combined is described in each specication for the "rated torque," "instantaneous
peak torque," "rated rotation speed" and "speed control range."
Model
Motor
BLM230-
oo
BLM230HP-
oo
BLM260-
oo
BLM260HP-
oo
BLM460-
oo
BLM460SHP-
oo
BLM460SHPK-
oooo
Driver
BMUD30-A2 BMUD30-C2 BMUD60-A2 BMUD60-C2
Rated output power (Continuous) 30 W 60 W
Power supply
input
Rated voltage
Single-phase
100-120 V
Single-phase
200-240 V
Three-phase
200-240 V
Single-phase
100-120 V
Single-phase
200-240 V
Three-phase
200-240 V
Permissible
voltage range
−15 to +10%
Rated frequency 50/60 Hz
Permissible
frequency range
±5%
Rated input
current
1.2 A
Single-phase: 0.7 A
Three-phase: 0.38 A
1.7 A
Single-phase: 1.0 A
Three-phase: 0.52 A
Maximum input
current
2.0 A
Single-phase: 1.2 A
Three-phase: 0.75 A
3.3 A
Single-phase: 1.9 A
Three-phase: 1.1 A
Rated torque 0.096 N·m (13.6 oz-in) 0.191 N·m (27 oz-in)
Instantaneous peak torque 0.144 N·m (20 oz-in) [80 to 2000 r/min] 0.287 N·m (41 oz-in) [80 to 2000 r/min]
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*
*
There are products, which maximum rotation speed is 3600 r/min, depending on the gearhead type.
Check the operating manual supplied with the motor.
Model
Motor
BLM5120-
oo
BLM5120HP-
oo
BLM5120HPK-
oooo
Driver
BMUD120-A2 BMUD120-C2
Rated output power (Continuous) 120 W
Power supply
input
Rated voltage
Single-phase
100-120 V
Single-phase
200-240 V
Three-phase
200-240 V
Permissible
voltage range
−15 to +10%
Rated frequency 50/60 Hz
Permissible
frequency range
±5%
Rated input
current
3.3 A
Single-phase: 2.0 A
Three-phase: 1.1 A
Maximum input
current
6.8 A
Single-phase: 4.1 A
Three-phase: 2.0 A
Rated torque 0.382 N·m (54 oz-in)
Instantaneous peak torque 0.573 N·m (81 oz-in) [80 to 2000 r/min]
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*
*
There are products, which maximum rotation speed is 3600 r/min, depending on the gearhead type.
Check the operating manual supplied with the motor.
