Preparation
−6−
3 Preparation
3.1 Checking the product
Verify that the items listed below are included.
Report any missing or damaged items to the branch or sales ofce from which you purchased the product.
□
Driver ..............................................................
1
unit
□
CN1 connector (3 pins) ................................
1
pc
□
CN4 connector (9 pins) ................................
1
pc
□
OPERATING MANUAL(this document) .....
1
copy
□
QUICK START GUIDE ....................................
1
copy
3.2 How to identify the product model

Driver
䐟 䐠 䐡 䐢
BMUD 60 - C 2
①
Driver type
BMUD
:
BMU
series driver
②
Output power
30
: 30 W
60
: 60 W
120
: 120 W
③
Power supply voltage
A
: Single-phase 100-120 V
C
: Single-phase, Three-phase 200-240 V
④
Reference number

Motor
䐟 䐠 䐡 䐢 䐣 䐤 䐨 䐩 䐪
 Parallel shaft gearhead GFV gearhead
Round shaft
䐪
 Right angle Hollow shaft Hypoid gear JH gearhead
䐟 䐠 䐡 䐣䐢 䐤 䐥 䐦 䐧 䐨
BLM 4 60 S H P - 5 A S
BLM 4 60 S H P K - 4 H 10 S
①
Motor type
BLM
: Brushless Motor
②
Frame size
2
: 60 mm (2.36 in.)
4
: 80 mm (3.15 in.)
5
: 90 mm (3.54 in.)
③
Output power
30
: 30 W
60
: 60 W
120
: 120 W
④
Motor classication
S
⑤
Motor connection method
H
: Connector type Blank: Cable type
⑥
Degree of protection for motor
P
: IP66 Blank: IP40
⑦
Combined motor
K
: Round shaft type (with key)
⑧
Frame size of combined motor
4
: 80 mm (3.15 in.)
5
: 90 mm (3.54 in.)
⑨
Gearhead type
H
:
JH
gearhead
⑩
Gear ratio • Motor shaft type
Number: Gear ratio of gearhead
A
: Round shaft type
AC
: Round shaft type (Shaft at)
⑪
Gearhead shaft type Blank: mm shaft type
A
: Inch shaft type
⑫
Material of output shaft
C
,
S
: Stainless steel
A
,
B
: Carbon steel
•
A code is added to the end of the model name for the product that the motor connector position has been changed.
