Outback Power Systems FX2024ET User Manual

31
Nominal DC Input Voltage Range 12VDC
Nominal AC Voltage / Frequency 230VAC / 50 HZ
Continuous Power Rating at 25C Ambient 2000VA
Continuous AC RMS Output at 25°C 8.7 Amps AC
Idle Power - Full AC Output ≈ 20 Watts DC
Idle Power - Search Mode 6 Watts DC
Typical E ciency 90%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 28 amps AC
Maximum Output Current - RMS (100 mSec) 20 amps AC
AC Overload Capability - Surge 4600VA
AC Overload Capability - 5 Second 4000VA
AC Overload Capability - 30 Minutes 2500VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range
160 to 300VAC
AC Input Frequency Range 44.0 to 56.0 Hz
DC Input Range 21.0 to 34.0 VDC
DC Input Current – Rated Power 200 Amps DC
Continuous Battery Charger Output 100 Amps DC
FX2012ET
APPENDIX RATINGS
Nominal DC Input Voltage Range 24VDC
Nominal AC Voltage / Frequency 230VAC / 50 HZ
Continuous Power Rating at 25C Ambient 2000VA
Continuous AC RMS Output at 25°C 8.7 Amps AC
Idle Power - Full AC Output ≈ 20 Watts DC
Idle Power - Search Mode 6 Watts DC
Typical E ciency 90%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 35 amps AC
Maximum Output Current - RMS (100 mSec) 25 amps AC
AC Overload Capability - Surge 5750VA
AC Overload Capability - 5 Second 4000VA
AC Overload Capability - 30 Minutes 3200VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range 160 to 300VAC
AC Input Frequency Range 44.0 to 56.0 Hz
DC Input Range 21.0 to 34.0 VDC
DC Input Current – Rated Power 100 Amps DC
Continuous Battery Charger Output 55 Amps DC
FX2024ET
