Outback Power Systems FX2024ET User Manual

34
RATINGS DETAILED
NOMINAL AC OUTPUT VOLTAGE OF AN FX SYSTEM
Single Phase 230VAC at 50 Hz
Parallel Stacked 230VAC at 50 Hz on one AC output leg
Three Phase Stacked 230VAC at 50 Hz per AC output leg (limit three) / 400VAC at 50 Hz between AC output legs
RECOMMENDED FX DC VOLTAGE RANGE
NOTE: The last two digits in the model number designate the nominal DC voltage.
Example: FX2024ET = 24V DC Voltage.
12V Systems 11 – 16VDC (VDC = volts DC)
24V Systems 22 – 32VDC
32V Systems 29 – 43VDC
48V Systems 44 – 64VDC
MAXIMUM DC LOAD CURRENT
NOTE: This is the maximum DC current the FX will draw from the battery when starting very large AC loads.
It is not used for sizing the DC disconnect or selecting DC cable gauge. It is used to select the minimum
reasonable battery capacity.
12V FXs 600ADC per FX (ADC = amps DC)
24V FXs 300ADC per FX
32V FXs 225ADC per FX
48V FXs 150ADC per FX
