5
2. Specifications
Indoor CS-E7NKEW, CS-XE7NKEW CS-E9NKEW, CS-XE9NKEW
Model
Outdoor CU-E7NKE CU-E9NKE
Performance Test Condition EUROVENT EUROVENT
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min. Mid. Max. Min. Mid. Max.
kW 0.75 2.05 2.40 0.85 2.50 3.00
BTU/h 2560 6990 8180 2900 8530 10200
Capacity
Kcal/h 650 1760 2060 730 2150 2580
Running Current A - 2.2 - - 2.5 -
Input Power W 240 470 580 245 535 730
Annual Consumption kWh - 235 - - 268 -
W/W 3.13 4.36 4.14 3.47 4.67 4.11
BTU/hW 10.67 14.87 14.10 11.84 15.94 13.97
EER
Kcal/hW 2.71 3.74 3.55 2.98 4.02 3.53
Power Factor % - 93 - - 93 -
dB-A 37 / 24 / 20 39 / 25 / 20
Indoor Noise (H / L / QLo)
Power Level dB 53 / - 55 / -
dB-A 45 / - 46 / -
Cooling
Outdoor Noise (H / L)
Power Level dB 60 / - 61 / -
kW 0.75 2.80 4.00 0.85 3.40 5.00
BTU/h 2560 9550 13600 2900 11600 17100
Capacity
Kcal/h 650 2410 3440 730 2920 4300
Running Current A - 3.0 - - 3.4 -
Input Power W 230 635 1.02k 240 735 1.30k
W/W 3.26 4.41 3.92 3.54 4.63 3.85
BTU/hW 11.13 15.04 13.33 12.08 15.78 13.15
COP
Kcal/hW 2.83 3.80 3.37 3.04 3.97 3.31
Power Factor % - 92 - - 94 -
dB-A 38 / 25 / 20 40 / 27 / 20
Indoor Noise (H / L / QLo)
Power Level dB 54 / - 56 / -
dB-A 46 / - 47 / -
Heating
Outdoor Noise (H / L)
Power Level dB 61 / - 62 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 2.90 / 900 / 3.22 3.62 / 1.15k / 3.15
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 2.35 / 930 / 2.53 2.88 / 1.18k / 2.44
Max Current (A) / Max Input Power (W) 4.7 / 1.02k 5.8 / 1.30k
Starting Current (A) 3.0 3.4
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (6 poles) Brushless (6 poles)
Compressor
Output Power W 650 700
