90
English
DVI-D/SLOT select
Selects a terminal to use.
[DVI-D]:
Uses DVI-D IN terminal.
[SLOT]:
Uses SLOT.
USB select
Selects a USB port to use for the USB function.
[MP1]:
Uses MP1 as a function operation terminal.
[MP2]:
Uses MP2 as a function operation terminal.
Note
●
Regardless of the setting, both terminals can be used
for power supply. (see page 30)
Quick input change mode
Sets the mode to switch the input at high speed.
[Off]:
Switches the input in normal mode.
[On]:
Switches the input in high speed mode between
the following inputs.
[HDMI1] / [HDMI2] / [DisplayPort] / [DVI-D] / [SLOT]
Note
●
Switching at high speed is possible only when the
types of signals are the same between inputs.
●
When switching the input at high speed, as for the
values of the position, size and image menu, images
are once displayed with the setting values for the
terminal before switching, and then images are
displayed with the setting values for the terminal after
switching.
To Next Page
