PHYSICAL
6
Section 1. Printer Overview
SPECIFICATION PTR3E
DIMENSIONS
Wide 10.4 in. (265 mm)
Deep 17.1 in. (435 mm)
High 13.4 in. (341 mm)
WEIGHT 39.6 lbs (18 Kg)
POWER REQUIREMENTS
Voltage
100 - 115 V , ±10 % (Default Setting)
220V , ±10 %
50/60 Hz, ±1%
Power Consumption 50W Idle
130W Operating
ENVIRONMENTAL
Operating Temperature 41° to 104°F (5° to 40°C)
Storage Temperature -0° to 104°F (-20° to 40°C)
Operating Humidity 15-85 % RH, non-condensing
Storage Humidity Max 90% RH, non-condensing
Electrostatic Discharge 8KV
REGULATORY APPROVALS
Safety UL, CSA, TUV, CE
RFI/EMI FCC Class A
All specifications subject to change without notice.
