4-14
4.3.12.2
Electromagnet 2 (Duplex Mode)
Pull out the connec
ting wires from
the electroma
gnet
,
unscrew the retaining
screws, and remov
e
the electroma
gnet.
4.3.13
Deliv
ery Component
Unscrew the retaini
ng screw
s and remove the deliv
er
y component.
4.3.14
Fuser Componen
t
1.
P
ull out the cable fro
m the fuser compone
nt.
57
59
