Pantum P3000 Series Maintenance Manual

4-16
2. Unscrew the screw fixed to the motor and remove the motor.
4.3.17 Pickup Roller
Unscrew the dowel on the pickup roller and remove the pickup roller.
4.3.18 Lower Cover
Unscrew the retaining screws on the lower cover, remove the lower cover, and unplug the
connecting wires from the sensor board.
