Parker Airtek TWB800 User Manual

TWP/TWB200 – TWP/TWB9000
70
MODEL TWB4000 TWB5000 TWB6000 TWB7500 TWB9000
DESICCANT PART ID
DESICCANT 25LB BAGS (QTY) AV1, AV2 PDA-1/8-25 (232) PDA-1/8-25 (288) PDA-1/8-25 (352) PDA-1/8-25 (456) PDA-1/8-25 (540)
FILTER ELEMENTS
COALESCER ELEMENT (QTY) PF1, PF2 6CU51-280 X 1 (3) 6CU51-280 X 1 (4) 6CU51-280 X 1 (4) 6CU51-280 X 1 (7) 6CU51-280 X 1 (7)
PARTICULATE ELEMENT (QTY) AF1, AF2 10DS85-360 X 1 (1) 10DS85-360 X 1 (1) 10DS51-280 X 1 (3) 10DS51-280 X 1 (4) 10DS51-280 X 1 (4)
CONTROL AIR FILTER ELEMENT (QTY) CF1 TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1) TP2201-PE (1)
BLOWER INTAKE ELEMENT BF1 TP1451-SDB-E 2C040-003 2C040-003 2C040-001 2C040-001
REPAIR KITS
INLET VALVE REPAIR KIT PV2, PV3 TP7661-BD-HP-RK TP7661-BD-HP-RK TP7661-BD-HP-RK TP7681-BD-HP-RK TP7681-BD-HP-RK
INLET VALVE ACTUATOR PV2, PV3 TP7631-BD-HP-A TP7631-BD-HP-A TP7631-BD-HP-A TP7681-BD-HP-A TP7681-BD-HP-A
EXHAUST VALVE REPAIR KIT PV1, PV4 TP7641-BD-HP-RK TP7641-BD-HP-RK TP7661-BD-HP-RK TP7661-BD-HP-RK
EXHAUST VALVE ACTUATOR PV1, PV4 TP7542-B-HP-A TP7542-B-HP-A TP7562-B-HP-A TP7562-B-HP-A TP7582-B-HP-A
PRE EXHAUST VALVE REPAIR KIT PV7, PV8 TP7520-P1-RK TP7520-P1-RK TP7520-P1-RK TP7520-P1-RK TP7520-P1-RK
OUTLET CHK VALVE REPAIR KIT CV1, CV2 TP7461-SWRK TP7461-SWRK TP7461-SWRK TP7481-SWRK TP7481-SWRK
PURGE CHK VALVE REPAIR KIT CV3, CV4 TP7441-SWRK TP7461-SWRK TP7461-SWRK TP7461-SWRK TP7481-SWRK
2% CHK VALVE REPAIR KIT CV5, CV6 TP7415-AB-RK TP7415-AB-RK TP7415-AB-RK TP7420-AB-RK
2% COOLING VALVE REPAIR KIT PV6 TP7610-P1-RK TP7610-P1-RK TP7610-P1-RK TP7615-P1-RK TP7615-P1-RK
REPRESS VALVE REPAIR KIT PV5 TP7615-P1-RK TP7615-P1-RK TP7615-P1-RK TP7620-P1-RK TP7620-P1-RK
REPLACEMENT PARTS
INLET VALVE PV2, PV3 TP7661-BD-HP TP7661-BD-HP TP7661-BD-HP TP7681-BD-HP TP7681-BD-HP
EXHAUST VALVE P1, PV4 TP7542-B-HP TP7542-B-HP TP7562-B-HP TP7562-B-HP TP7582-B-HP
PRE EXHAUST VALVE PV7, PV8 TP7520-P1 TP7520-P1 TP7520-P1 TP7520-P1 TP7520-P1
OUTLET CHECK VALVE CV1, CV2 TP7461-SW TP7461-SW TP7461-SW TP7481-SW TP7481-SW
PURGE CHECK VALVE CV3, CV4 TP7441-SW TP7461-SW TP7461-SW TP7461-SW TP7481-SW
2% CHECK VALVE CV5, CV6 TP7415-AB TP7415-AB TP7415-AB TP7420-AB
2% COOLING VALVE PV6 TP7610-P1 TP7610-P1 TP7610-P1 TP7615-P1 TP7615-P1
2% COOLING CONTROL VALVE S6 TP8101-D TP8101-D TP8101-D TP8101-D TP8101-D
REPRESS CONTROL VALVE S5 TP8101-D TP8101-D TP8101-D TP8101-D TP8101-D
REPRESSURIZATION VALVE PV5 TP7615-P1 TP7615-P1 TP7615-P1 TP7620-P1 TP7620-P1
CONTROL SOLENOID VALVE S2A, S2B, S3A, S3B TP8101-1D TP8101-1D TP8101-1D TP8101-1D TP8101-1D
CONTROL SOLENOID VALVE S1, S4, S7, S8 TP8101-1D TP8101-1D TP8101-1D TP8101-1D TP8101-1D
DRAIN VALVE S10, S11 TP8003 TP8003 TP8003 TP8003 TP8003
MUFFLER, EXHAUST ES1, ES2 TP4220-1 TP4220-1 TP4220-1 TP4220-1 TP4220-1
FILTER, CONTROL AIR CF1 TP2201-P TP2201-P TP2201-P TP2201-P TP2201-P
SAFETY RELIEF VALVE PSV1, PSV2 TP7120 TP7120 TP7120 TP7120 TP7130-150
PRESSURE GAUGE PI1, PI2 LP1045 LP1045 LP1045 LP1045 LP1045
ORIFICE 2% COOLING RO1 TP4356 TP4362 TP4368 TP4375 TP4381
BACKUP PURGE ORIFICE RO2 TP4175 TP4187 TP41100 TP41112 TP41112
THERMOCOUPLE
TC1,TC2,TC3,TC4,TC5,TC6
TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD
VESSEL MANWAY GASKET AV1, AV2 FM21216-G FM21216-G FM21216-G FM21216-G FM21216-G
HEATER HT1 TP3685-4 TP37100-8 TP37120-N4 TP37150-N4 TP37180-N4
BLOWER BL1 TP1798-SDB TP1799-SDB TP1799-SDB TP1799-25 TP1799-40
BLOWER BELT 2A041-539 2A041-539 2A041-539 2A045-533
BLOWER TENSIONER WITH IDLER B003-429 B003-429 B003-429
BLOWER IDLER, DUAL BEARING 2C116-001 2C116-001 2C116-001
BLOWER DAMPER 2C111-044 2C111-044 2C111-044
BLOWER HEAD 2C228-081 2C228-081 2C228-081 2C228-091
PRESSURE TRANSDUCER PT1, PT2, PT3, PT4 TP2451 TP2451 TP2451 TP2451 TP2451
FLOW SWITCH FS1 DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB DP6060-S-N4-SDB
HEATER CONTACTOR
C1,C2,C3,C4,C5,C6,C7,C8
ES5075 ES5075 ES5075 ES5075 ES5075
BLOWER CONTACTOR MS1 ES5003-20AF ES5003-20AF ES5003-30AF ES5003-30AF
STARTER OVERLOAD OL ES5001-TF-24.0 ES5001-TF-29.0 ES5001-TF-29.0 ES5001-TF-35.0
HEATER FUSE EF3050-F EF3040-F EF3060-F
BLOWER FUSE EF3030 EF3045 EF3045 EF3060
PLC PLC1 TP2681-PLC-B9000 TP2681-PLC-B9000 TP2681-PLC-B9000 TP2681-PLC-B9000 TP2681-PLC-B9000
HMI DISPLAY HMI TP2681-HMI-B9000 TP2681-HMI-B9000 TP2681-HMI-B9000 TP2681-HMI-B9000 TP2681-HMI-B9000
FUSE, 1 AMP F1, F3 EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD EF0100-2-TD
FUSE, 3 AMP F2 EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD EF0300-2-TD
MEMORY CARD TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM TP2681-MEM
MODELS WITH POWER LOCK
DEWPOINT PROBE AE1 TP2190-1 TP2190-1 TP2190-1 TP2190-1 TP2190-1
MODELS WITH NEMA 4
NEMA 4 THERMOCOUPLE
TC1,TC2,TC3,TC4,TC5,TC6
TP2083-N4-12 TP2083-N4-12 TP2083-N4-12 TP2083-N4-12 TP2083-N4-12
MODELS WITH OUTDOOR PACKAGE
BLOWER INTAKE ELEMENT BF1
MODELS WITH INSTRUMENTATION OPTION
PRESSURE GAUGE PI4, P5 LP1020 LP1020 LP1020 LP1020 LP1020
TEMPERATURE GAUGE TG1, TG2 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25 LT3250-.25
Blower Purge Spare Parts List (Flow schematic drawing# FS11688)
PART NUMBER
MAN-TWB9000AB-SPARE PARTS Rev -
