Parker Airtek TWB800 User Manual

TWP/TWB200 – TWP/TWB9000
74
TECHNICAL SPECIFICATIONS
Mod-
el
Ca-
pacity
SCFM
Min PSI Air In/Out
Size
Air In/Out
Connec-
tion
Power FLA Heater
KW
Blower
HP
Dryer
Avg
KW
LBS
Desiccant
per Vessel
Operating
Weight
LBS
200 200 80 1 1/2 IN NPT 240/1/60 11.4 6 0.75 2.7 150 1500
300 300 80 1 1/2IN NPT 460/3/60 12.5 6 1.5 4.3 235 1900
400 400 80 2 IN NPT 460/3/60 16.7 9 1.5 5.5 300 2180
500 500 80 2 IN NPT 460/3/60 21.5 12 3 7.4 375 2840
600 600 80 2 IN NPT 460/3/60 21.5 12 3 8.5 450 3420
800 800 80 2 IN NPT 460/3/60 29.1 15 5 11.9 600 4490
1000 1000 80 3 IN FLG 460/3/60 32.8 18 5 14.2 725 5700
1200 1200 80 3 IN FLG 460/3/60 39.0 25 4 16.1 850 6300
1500 1500 80 3 IN FLG 460/3/60 48.6 30 7.5 21.3 1100 7165
2000 2000 80 4 IN FLG 460/3/60 58.2 38 7.5 27.3 1500 9850
2600 2600 80 4 IN FLG 460/3/60 75.6 50 10 35.6 1900 12210
3000 3000 80 6 IN FLG 460/3/60 87.7 60 10 40.3 2200 12650
4000 4000 80 6 IN FLG 460/3/60 122.7 85 15 54.6 2900 18910
5000 5000 80 6 IN FLG 460/3/60 147.1 100 20 68.8 3600 21590
6000 6000 80 6 IN FLG 460/3/60 171.1 120 20 80.7 4400 24890
7500 7500 80 8 IN FLG 460/3/60 212.9 150 25 100.8 5700 29490
9000 9000 80 8 IN FLG 460/3/60 CF 180 40 125.7 6750 34080
Design Conditions of 100 psig at 100°F inlet air, 40° to 100°F ambient air.
To obtain dryer capacity at different operating conditions, multiply nominal capacity X temperature correction
factor X pressure correction factor.
Maximum Inlet Temperature (°F) 90 95 100 105 110 115 120
Temperature Correction Factor 1.17 1.15 1.00 0.87 0.76 0.66 0.58
Minimum Inlet Pressure (PSIG) 80 90 100 110 120 130
Pressure Correction Factor 0.83 0.91 1.00 1.09 1.17 1.26
