INTELLICHEM
®
Controller Installation and User’s Guide
6
Basic display mode
Advanced display mode
The main IntelliChem
®
Controller status screen can be setup to display basic or advanced
system information. To setup the Display Mode, see “Configuration” menu on page 17.
The Basic display mode shows the current pH and ORP measurements including a
message describing any existing pH (line two) and ORP (line four) alarms. The Advanced
display mode shows all the current measurements and alarm messages as well as dose
and mix timers showing the progress of those processes.
The Basic mode displays the current pH and ORP
measurements (pH in10th and ORP in 5mV) with any alarms
Display Modes
Press MENU / Auto Setup 
Use the Auto Setup feature for first-time setup or standard configurations. Follow the on-
screen prompts and enter information about your system configuration (pH/ORP internal
or external pumps, pool size, filter time, chemical container size etc). IntelliChem uses
this information to automatically setup reminder times, calculate feed times, proportional
limits and alarms. The following describes the Auto Setup screen. Press the MENU button
to access the Auto Setup menu. To change a menu setting or value press the / Up/
Down arrow button. Press the MENU button to save each selection.
The displays shows t
H CO2 - OR
Previous Values: Use to recalculate new dose times etc., if no custom settings exist. Not
recommended for custom settings; use the menu directly to make these changes.
Reset All: Make major configuration changes that may have conflicts with previous
settings.
IntelliChem Auto
__Setup Wizard__
Press MENU to go to
each new step
Would you
like to use
previous values?
[Yes | Reset All]
Auto Setup Sequence
>OK or <OK is displayed as soon as the value exceeds
alarm trip point. That is replaced with “HIGH/LOW” after the
Dosing will
resume when you
_exit this menu_
Press any button
Note: Alarms are displayed on all Basic and Advanced modes.


To exit Auto Setup,
press
pH >OK 7.4
-.72 Scaling
ORP OK 730
Monitoring
pH HIGH 7.91
pH Dose Limit
ORP OK 683
Mixing 00:07:54
Displays three different Alarms. The example screen shows:
Dose limit, high reading and chemical tank low alarm. These
can co-exist. The advanced mode displays the current pH and
ORP high precision measurements (extra digit. e.g. pH=100th -
ORP=1mV resolution), alarms, tank levels, process messages
and timers.
Basic and Advanced Display with Error Messages
If IntelliChem detects the pool water circulation pump is not
active, a NO FLOW message is displayed. ORP and pH values
are not measured when there is no flow, and therefore not
displayed.
NO FLOW DETECTED
Check pump, ow
Cell, lter,
and valves.
Press UP/DWN to select.
Press MENU. (Resetting
defaults and Password).
Press MENU.

