INTELLICHEM
®
Controller Installation and User’s Guide
INTELLICHEM
®
Controller Installation and User’s Guide
39
Wiring IntelliChem
®
Controller AC Power to Filter Pump Relay
IntelliChem AC Power Wiring Instructions: When using IntelliChem as
a stand alone device (with a time clock) or with an IntelliChlor salt chlorine
generator, IntelliChem MUST BE CONNECTED TO THE LOAD SIDE OF THE
FILTER PUMP RELAY located in the load/power center (see page 40 for
IntelliChem AC power wiring diagram). This ensures that IntelliChem will only
dispense chemicals when the filter pump is ON.
For IntelliTouch
®
, EasyTouch
®
or SunTouch
®
control system using an IntelliFlo
®
pump (or 2-speed pump) and an IntelliChlor
®
(SCG), the IntelliChlor controller
AC power center wires must also be connected to the LOAD SIDE OF THE
MAIN FILTER PUMP RELAY located in the load/power center (see page 40 for
diagram). This ensures that IntelliChem controller and IntelliChlor SCG only
produce chlorine when the main filter pump is on.
CONNECTING TO AN AUTOMATION CONTROL SYSTEM
The following wiring diagram (see next page) shows the IntelliChem controller AC power
wiring and COM port connections to the EasyTouch, IntelliTouch and SunTouch control
system.
