INTELLICHEM
®
Controller Installation and User’s Guide
INTELLICHEM
®
Controller Installation and User’s Guide
9
Auto Setup Sequence (Continued)
pH
pH Set Point: 7.5
pH Alarm High: 7.8
pH Alarm Low: 6.8
pH Alarm Delays: 5 min. for both
Sensitivity: Low (Off for CO2)
ORP
ORP Set Point: 700
ORP Alarm High: 750
ORP Alarm Low: 650
ORP Alarm Delays: 5 min. for both
Sensitivity: Low (Off for IntelliChlor
®
Salt Chloriine Generator)
pH Lockout: 7.8
IntelliChem Controller System Default Values
Miscellaneous Default Values
Display Mode: Basic
Control Panel LED Brightness: 10%
Menu Timer: M:02 S:30
Menu Backlight Timer: M:00 M:20
Power-On Delay: 14 minutes
Flow Switch Delay: 1 minute
Dose Priority: Simultaneous dosing
Password 1234 - Lock = Off
Continue on next page.

Is your pool
water balanced?
[No]

Balance water
chemistry before
beginning automatic
control
Finished Setup.
Verify your new
settings in the
pH & ORP menus!

NO
YES

Note: The units used for dose size in the main menus
will automatically be set to milliliters(ml) if either the
pool volume is set to less than 4k gallons or the
container size is specified in liters.
Note: 1 oz = approximately 3 ml.
