20 EQUIPMENT INSTALLATION
Rev E
Figure 12
Regenerant Tank Check Valve (not provided)*
* Furnished as an option from conditioner system manufacturer.
Electrical Connection
CAUTION: This valve and control are for dry location use only unless used
with a Listed Class 2 power supply suitable for outdoor use.
All 700 Series controllers operate on 12-volt alternating current power supply.
This requires use of the supplied AC adapter. A variety of AC adapters are
available for different applications. These AC adapters are available from your
supplier. They include:
AC Adapter
Input
Voltage
Application Part Number
Standard wall-mount AC
adapter
120V 60Hz Standard indoor
application
1000811
Outdoor rated AC
adapter
120V 60Hz UL listed for
outdoor
installations
1235448
International option AC
adapters
Varies based
on country
Standard indoor
application
See Parts Lists
Section
