Interfaces:
Different connection types can be found on the back of the housing depending on what inter-
face is used. The following diagrams show the pin assignments:
Connection interface: SSI (Synchronous Serial Interface)
Figure 4.4 Connection Assignment SSI
The connector housing is located on the shield.
4.5 Scope of Delivery
The scope of delivery includes:
• R1000
• Safety information and laser label
• Grounding set
4.6 Accessories
You will find accessories online at www.pepperl-fuchs.com on the product page for the rele-
vant device or on the relevant datasheet.
1 24 V power supply
2 Do not connect
3 0 V (GND)
4 Do not connect
1 D+
2 D-
3 CLK+
4 CLK-
5 n.c.
