Distance Sensors

Settings

2021-09

Display Timeout

You use this menu item to set the time after which the display is automatically deactivated. Pos-

sible values are 5 min, 30 min, and 60 min.

The factory default setting is "5 min."

7.3.3 Serial Menu Item

Output Mode

You use this menu item to configure the serial interface. The modes that can be set are "SSI:

Binary Code" and "SSI: Gray Code." The factory default setting is "SSI: Gray Code."

SSI Error Bit

You use this menu item to configure the behavior of the SSI error bit (see chapter 9.1.2). The

SSI error bit can optionally be set,

• if an error substitute value is present,

• if an error substitute value is present or an error occurs, or

• if a substitute error value is present or an error or warning occurs.

The menu entry is visible only if the output mode is set to "SSI: Binary Code" or "SSI: Gray

Code."

7.3.4 Miscellaneous Menu Item

Versions

You can use this menu item to check the hardware version, firmware version, and interface ver-

sion.

Factory Settings

You can use this menu item to reset all of the device's settings to the factory default settings. A

security prompt is displayed to protect against accidental resets.
