6 Commissioning
Commissioning the Device
1.
Connect the distance measurement device to the power supply.
The device starts an initialization phase for a maximum of 5 seconds.
2.
If the device was not aligned correctly, refer to the messages on the display.
3.
If the device was aligned correctly with the reflector and valid measurements are obtained, the
red error LED (ERR) goes out and the yellow target LED (TGT) lights up.
The device is ready for operation.
The device provides valid measured values.
4.
Allow a warm-up phase of 10 minutes for the distance measurement device.
The distance sensor achieves the specified measurement accuracy after 6 minutes.
6.1 Display
6.1.1 Operating Indicator
During normal operation (menu not active), an operating indicator provides information about
the state of the device.
In addition to the currently measured distance, the display shows important configurable set-
tings of the device.
Figure 6.1 Example display
2.365 m
25 ms
0
FWD
Display off
SSI: Binary
Menu
Measurement Delay Counting Direction Offset Communication Interface
25 ms ▶FWD Forward ▶0◀ No offset <blank> SSI deactivated
◀REV Reverse ▶+◀ Positive offset SSI:
Binary
SSI with binary coding
▶-◀ Negative offset SSI: Gray SSI with gray coding
Table 6.1 Description of the display contents
bold = example
