2021-09
12
Distance Sensors
Installation
5 Installation
5.1 Storage and Transport
Pack the device for storage and transport in a way that protects it against impact.
Protect the device against moisture.
Always store and transport the device in the original packaging.
Also take note of the permitted ambient conditions.
5.2 Unpacking
Check the product for damage while unpacking. If the product should be damaged, inform the
post office or parcel service and notify the supplier.
Retain the original packaging in case the device must be stored or shipped again at a later
date.
Should you have any questions, please contact Pepperl+Fuchs.
5.3 Mounting
Mounting Aid
The mounting aid OMH-R1000-02 enables fine adjustment. To align the laser beam of the
device on the reflector as centrally as possible, the device can be adjusted by ±2.5° along the
Y-axis or Z-axis using the bracket. The maximum adjustment is ±90°.
Note
In all cases, avoid subjecting the device to condensation, as this could have an effect on
internal parts and cause damage.
Caution!
Risk of damage due to improper operation.
Improper operation can result in damage to the device.
• Do not point the sensor into the sun.
• Protect the sensor against direct and prolonged sunlight.
• Prevent condensation from forming by ensuring that the sensor is not subjected to any
major temperature fluctuations.
• Do not subject the sensor to any influences caused by aggressive chemicals.
In particular, avoid agents that contain hydrocarbons, such as mineral spirits, alcohol, or
solvents.
• Keep the glass on the device and the reflector clean.
Use soft cloths. If necessary, clean the glass with water and a small amount of washing-up
liquid.
Note
Use M6 mounting screws with 8 mm thread length.
