Pepperl+Fuchs WCS Series User Manual

2020-01
20
WCS* Read Head Position Encoding System
RS-485 Interface (LS1xx*, LS2xx*)
Base types LS246/LS256
Base types LS*1xS/LS*2xS
Base types LS*3xS/LS*6xS
Base types LS*3xS/LS*6xS
Adjusting the Display
You can rotate the character position on the display 180° using the S1D DIP switch. This allows
you to read the displayed values easily regardless of the installation position of the read head.
Read head type
(* = 1 or 2)
Configuration switch "S1"
Baud rate1 2 3 4
WCS2B-LS*46
WCS3B-LS*46
X X OFF OFF 19.2 kBaud even parity
WCS2B-LS*47
WCS3B-LS*47
X X OFF ON 19.2 kBaud no parity
WCS2B-LS*56
WCS3B-LS*56
X X ON OFF 9.6 kBaud even parity
WCS2B-LS*57
WCS3B-LS*57
X X ON ON 9.6 kBaud no parity
Read head type
(* = 1 or 2, x = 1, 6, or 7)
Configuration switch "S1"
Baud rate1 2 3 4
WCS3B-LS*1xS X OFF X X 187.5 kBaud
WCS3B-LS*2xS X ON X X 62.5 kBaud
Read head type
(* = 1 or 2, x = 1, 6, or 7)
Configuration switch "S1"
Baud rate1 2 3 4
WCS3B-LS*6xS X OFF X X 38.4 kBaud
WCS3B-LS*3xS X ON X X 31.25 kBaud
Read head type
(* = 1 or 2, x = 1, 6, or 7)
Configuration switch "S1"
Baud rate1 2 3 4
WCS3B-LS*4xS X OFF X X 19.2 kBaud
WCS3B-LS*5xS X OFF X X 9.6 kBaud
WCS3B
Display position
Configuration switch "S1D"
Comment1 2
0° OFF OFF The displayed value can be read on a
code rail mounted upright.
180° ON ON The displayed value can be read on a
code rail mounted suspended.
