WCS* Read Head Position Encoding System
Appendix
2020-01
73
12 Appendix
12.1 Cable Overview
The cable types listed below represent a selection of the types offered by Pepperl+Fuchs. Fur-
ther cable types can be found on our website.
RS-485 (LS1xx*, LS2xx*)
Note
For cables that you can assemble yourself, observe the cable length restrictions specified by
the interface specification. In the respective interface chapters you will find recommendations
for the maximum cable length.
Cable Description
Pre-configured cable
V15-G-2M-PUR-ABG M12 single-ended female cordset, five-pins, straight, 2 m PUR cable,
shielded,
V15-G-5M-PUR-ABG M12 single-ended female cordset, five-pins, straight, 5 m PUR cable,
shielded,
V15-G-10M-PUR-
ABG
M12 single-ended female cordset, five-pins, straight, 10 m PUR cable,
shielded,
Configurable female cordset and meter goods
V15-G-ABG-PG9 Five-pin single-ended female cordset, field attachable, shielded
V15-G-ABG-PG9-FE Five-pin single-ended female cordset, field attachable, shielded with
grounding terminal
WCS-DCS
Available by the meter, six-pin data cable + shield, 0.14 mm
2
3 x 2 twisted wire pair
WCS-DCF
Available by the meter, six-pin data cable + shield, 0.25 mm
2
3 x 2 twisted wire pair, suitable for drag chains
