6.3 Software Configuration
The read head is integrated into the network via an EDS file (electronic datasheet) with a proj-
ect planning tool such as RSLogix 5000. The EDS file contains all information about device-
specific parameters and operating modes.
6.4 Data Protocols
Two data protocols are supported: data protocol 1 and data protocol 2.
The data protocols always have a length of 8 bytes. The data protocol is selected via the fourth
switch of the 4-way DIP switch on the PCB on the side of the read head (see chapter 6.2).
• DIP4-4 = OFF ... CAN data protocol 1
• DIP4-4 = ON ... CAN data protocol 2
Data protocol 1
Data protocol 2
Note
Downloading the EDS file
You can find the relevant EDS file in the Software section of the product detail page for the
device.
To access the product detail page for the device, go to http://www.pepperl-fuchs.com and type
e.g., the product description or the item number into the search function.
Bit Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0
0 0 0 0 0 P18 P17 P16
Byte 1
P15 P14 P13 P12 P11 P10 P09 P08
Byte 2
P07 P06 P05 P04 P03 P02 P01 P00
Byte 3
0 0 SST DB ERR OUT 0 0
Byte 4
0 SP6 SP5 SP4 SP3 SP2 SP1 SP0
Byte 5
0 0 0 0 0 0 0 0
Byte 6
0 0 0 0 0 0 0 0
Byte 7
0 0 0 0 0 0 0 0
Bit Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0
0 0 SST DB ERR OUT 0 0
Byte 1
P07 P06 P05 P04 P03 P02 P01 P00
Byte 2
P15 P14 P13 P12 P11 P10 P09 P08
Byte 3
0 0 0 0 0 P18 P17 P16
Byte 4
0 SP6 SP5 SP4 SP3 SP2 SP1 SP0
Byte 5
0 0 0 0 0 0 0 0
Byte 6
0 0 0 0 0 0 0 0
Byte 7
0 0 0 0 0 0 0 0
