2:5
Preparations
Bobbin winding
1. Place the thread spool on the spool pin in
horizontal position. Slide a spool cap tightly
against the spool.
2. Place the thread into the thread guide (A) from
back to front. Pull the thread clockwise around
the bobbin winder tension disc (B).
3. Thread through the hole in the bobbin (C) from
the inside to the outside.
4. Place an empty bobbin on the bobbin spindle.
5. Push the bobbin lever to the right to wind.
A pop-up appears on the screen to inform
you that bobbin winding is on. Press the
foot control or the start/stop button to start
winding the bobbin.
When the bobbin is full, the bobbin winding
will slow down and stop automatically. The
pop-up closes. Remove the bobbin and cut the
thread using the bobbin thread cutter (D).
A
B
D
C
D
