6 Connecting devices
No supplied cables are used with these connections:
• Pleasepurchasethenecessarycablesatyourlocalstore.
Before you connect AC power cord:
BesureotherdevicesareconnectedproperlybeforepluggingintheAC
powercord.
Selecting your connection quality
HDMI - Highest quality
Supportshigh-denitionDigitalsignalsandgiveshighestpictureand
soundquality.VideoandAudiosignalsarecombinedinonecable.You
mustuseHDMIforfullhigh-denitionvideoandtoenablePhilips
EasyLink.
Note
• PhilipsHDMIsupportsHDCP(High-bandwidthDigitalContentsProtection).HDCP
isaformofDigitalRightsManagementthatprotectshighdenitioncontentinBlu-ray
discsorDVDs.
• TheHDMI-ARCconnectorontheTVfeaturesHDMI-ARCfunctionality.Thisallows
outputofTVAudiotoanHDMI-ARC-compliantdevice.
Component (Y Pb Pr) - High quality
Supportshigh-denitionAnalogsignalsbutgiveslowerpicturequalitythan
HDMI.Component(Y/Pb/Pr)VideocablescombineRed/Green/Blue
videocableswithRed/WhiteAudio(L/R)cables.Matchthecable
colorswhenyouconnecttotheTV.
Composite - Basic quality
ForAnalogconnections.CompositeVideo/AudioAnalogcableusually
combineaYellowvideocablewithRed/WhiteAudio(L/R)cables.
Withthisunit,YellowcablemustbeconnectedtoY(Green)of
ComponentVideoInputjacks.
Connecting your devices
HDMI Digital connection
HDMIconnectionoffersthehighestpicturequality.
HDMI(High-DenitionMultimediaInterface)transportshighdenition
Digitalvideoandmulti-channelDigitalAudiothroughasinglecable.
ININ OUT
set-top box
or
Blu-ray disc player
or
HD game console
HDMI cable
HDMI-DVI connection
ThisunitcanbeconnectedtoyourdevicethathasaDVIterminal.
UseanHDMI-DVIconversioncableforthisconnectionanditrequires
AudiocableforAnalogAudiosignalaswell.
ININ
OUT
IN
IN
OUTOUT
HDMI-DVI
conversion cable
Audio (L/R) cables
cable receiver or
satellite box with the
DVI Output jack
Audio dongle
Note
• UseanHDMIcablewiththeHDMIlogo(acertiedHDMIcable).HighSpeedHDMI
cableisrecommendedforthebettercompatibility.
For HDMI connection
• Theunitaccepts480i/480p/720p/1080i,1080p24/30/60Hzofvideosignals,32kHz
/44.1kHzand48kHzofAudiosignals.
• Thisunitaccepts2channelAudiosignal(LPCM)only.
• ThisunitacceptsonlysignalsincompliancewithEIA861.
For HDMI-DVI connection
• Theunitaccepts480i,480p,720p,1080iand1080pvideosignals.
• HDMI-DVIconnectionrequiresseparateAudioconnectionsaswellandtheAudio
signalsareoutputasAnalog(L/R)Audio.
• DVIdoesnotdisplay480iimagewhichisnotincompliancewithEIA/CEA-861/861B.
 Continued on next page.
