PIAGGIO MSS X10 500ie Executive User Manual

58. Fuel pump
59. Diagnostics socket
60. Left front daylight running light
61. Right front daylight running light
62. Left rear tail light bulb
63. Right rear tail light bulb
64. Left side control lighting
65. Right side control lighting
66. License plate light bulb 12V-5W
67. Horn
68. Horn button
69. N.2 stop buttons
70. Engine starter button
71. Left stop light
72. Right stop light
73. Light switch
74. Headlight
75. Headlight relay
76. Pre-installation of «blue dash / anti-theft device»
77. Fuse No. 10- 40A for ABS system
78.Shock absorber adjustment device
79. Shock absorber adjustment button "UP"
80. Shock absorber adjustment button "DOWN"
81. Encoder for shock absorber electric device
82. Shock absorber actuator
83. Shock absorber adjustment device ground node
84. CDI injection control unit ground node
85. Engine signalling relay inhibited
86. Diode 1A
87. ASR Button
88. ABS control unit
89. Front tone wheel sensor for ABS
90. Rear tone wheel sensor for ABS
91. Resistance 120ohm termination of CAN line
Key
Ar: Orange Az: Light Blue Bi: White Bl: Blue Gi: Yellow Gr:Grey
Ma:Brown Ne: Black Ro: Pink Rs: Red Ve: Green Vi: Purple
MSS X10 500ie Executive Electrical system
ELE SYS - 41

PIAGGIO MSS X10 500ie Executive Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	493 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Seat Height	760 mm
Fuel Capacity	15.5 liters
ABS	Yes
Front Tire	120/70-15
Width	800 mm
Torque	46 Nm @ 5, 250 rpm
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual hydraulic shock absorbers
Front Brake	Double disc
Rear Brake	Single disc
Rear Tire	150/70-13
