PIAGGIO MSS X10 500ie Executive User Manual

4 Live positive from fuse F8 (3A) for daylight run-
ning light - License plate light - control lighting -
instrument panel lighting (Yellow-Black)
5. Live positive from battery for power supply of
fuses F5-F6-F7-F8 (Orange)
6. Live positive from battery for power supply of
fuses F5-F6-F7-F8 (Orange)
7. Live positive from battery for power supply of
fuses F5-F6-F7-F8 (Orange)
8. Live positive from battery for power supply of
fuses F5-F6-F7-F8 (Orange)
9. Direct battery positive for power supply of fuses
F1-F2-F3-F4 (Red)
10. Direct battery positive for power supply of
fuses F1-F2-F3-F4 (Red)
11. Direct battery positive for power supply of
fuses F1-F2-F3-F4 (Red)
12. Direct battery positive for power supply of
fuses F1-F2-F3-F4 (Red)
13. Battery positive from fuse F1 (15A) for LV
socket - turn lights device command - instrument
panel - Blue Dash - saddle actuator - fuel door ac-
tuator - Helmet compartment lighting (Red-Blue)
14. Battery positive from fuse F2 (10A) for Head-
light (Grey)
15. Battery positive from fuse F3 (10A) for injection
control unit CDI - Injector - electric fan relay - HV
coil - fuel pump (Red-White)
16. Battery positive from fuse F4 (7.5A) for electric
fan (Red-Green)
MSS X10 500ie Executive Electrical system
ELE SYS - 99

PIAGGIO MSS X10 500ie Executive Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	493 cc
Cooling System	Liquid cooled
Fuel System	Electronic fuel injection
Seat Height	760 mm
Fuel Capacity	15.5 liters
ABS	Yes
Front Tire	120/70-15
Width	800 mm
Torque	46 Nm @ 5, 250 rpm
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual hydraulic shock absorbers
Front Brake	Double disc
Rear Brake	Single disc
Rear Tire	150/70-13
