Fig. 15 - Removing wheel
REPLACING BULBS
In order to approach to the headlamp bulbs, remove the upper cover «C» of the
handlebars (fig. 19) acting as follows:
- Take off the four screws «V», placed on the lower part of the handlebars.
- Lift the cover «C» and rotate it sufficiently anticlockwise (as shown in fig. 19) in order to
permit the bulb holder extraction.
For the assembling of the cover «C» carry out a vice versa procedure to the above
mentioned one.
Fig. 16 – Brake adjustment
