MC012C-AS00 TRANSAXLE: HYDRAULIC AND PARK BRAKE SYSTEMS Park Brake System
Page 6-36 2003 Pioneer 1200/1200SE Gasoline Vehicle Maintenance and Service Manual
6
Park Brake Adjustment, Continued:
6. With the vehicle on flat ground and the Forward/Reverse handle in the NEUTRAL position, push the vehi-
cle by hand. If the wheels move when the vehicle is pushed, continue tightening the conical nut until the
vehicle can no longer be pushed.
7. Loosen the conical nut two full revolutions.
8. Tighten the equalizer jam nut (11) against the conical nut (23), using the double-wrench method, to 55
in-lb (6.3 N·m).
9. The park brake should now be adjusted so that the vehicle will not roll when pushed with the park brake
latched in the fourth notch (four clicks from the bottom of its travel).
10. Perform all of the brake system inspections to ensure that both the hydraulic brake system and the park
brake system are adjusted and operating correctly before placing the vehicle into service. See Brake
System Inspection on page 6-1.
