Piper Products RCM051 User Manual

- 26 -
GB
4.3.2 Simbols descriptions
On/Off control board
Start/Stop of a chilling phase.
Select HARD chilling (+3°C) or freeze (-18°C) cycle
Select chilling +3°C
Select freeze -18°C
Confirmation Blast chilling and Blast freezer with
standard probe
Value decrease.
Value increase.
Start up of Defrosting process
Heat by extraction of inserted Probe
Symbol for Cold room Temperature.
Symbol for Functioning heat probe.
Symbol for Chilling/Freeze Cycle per Probe.
Symbol for Chilling/Freeze Cycle per Time span.
Symbol for Sterilization in progress.
Symbol for functioning selected chilling cycle (+3°C) SOFT
Symbol for functioning selected freeze cycle (-18°C) SOFT
Symbol for selected HARD phase.
Symbol for Chilling Phase in progress.
Symbol for Preservation Phase in progress.
Symbol for Machinery in Stop Mode.
4.4 Detailed description of keys on control panel.
